iz6





İZ6

Profile Web Size       Between 150 and 350 single or multi-type machine
Steel Gauge Thickness  1.6-3.0 mm
Profile Type C/U  or SIGMA
Cordon Forming on Profile Flanges Yes
Printer Inkjet Type
Electronically Controlled Automatic Toolhead Oiling System Yes
Production Speed  300 m/hour
Dimensions 5750 mm x 1250 mm x 1600 mm
Main Power Supply 3 Phase, 380-400 V AC 50/60 Hz
Total Power 30 KW
Working Environment Temperature (-10°C ~ 40°C) if above or below this range optional cooling system
Hydraulic Tank Capacity 120 L
User Interface Touchscreen PC WIN 7 OS
Weight 5800 Kg
Decoiler 6 Tons
Design Software VERTEX BD FRAMER
Production Software İZFORM OS
